مستشعر الأكسجين المذاب

Q: Can the sensor measure accurately at very low flow or in static water?

Yes.This sensor uses optical fluorescence technology and does not consume oxygen during measurement. The reading is independent of flow velocity, making it highly reliable in low-flow or stagnant conditions.

Q: Will air bubbles affect the dissolved oxygen measurement?

The optical measurement principle is far less sensitive to bubbles than electrochemical sensors. Occasional bubbles do not significantly affect readings, especially in aeration tanks or mixed water environments.

Q: How stable is the sensor for long-term monitoring?

The sensor features minimal annual drift and no electrolyte consumption. Compared to membrane-based DO probes, it maintains accuracy over long periods with significantly reduced recalibration frequency.

Q: كم مرة يحتاج المستشعر إلى صيانة؟

Routine maintenance is minimal.There is no membrane or electrolyte to replace. The fluorescent cap has a long service life and can be easily replaced when required, reducing downtime and maintenance cost.

Q: Is RS485 communication compatible with PLC or SCADA systems?

Yes.The sensor supports RS485 communication, typically using Modbus protocol, allowing seamless integration with PLC, DCS, SCADA, and data logging systems.

Q: Can this sensor be used in harsh wastewater environments?

Absolutely.With an IP68-rated housing and 316L stainless steel + PPS construction, the sensor is designed for continuous submersible operation in corrosive, high-humidity, and industrial wastewater conditions.

Designed for continuous dissolved oxygen monitoring in water and wastewater processes, this optical dissolved oxygen sensor eliminates the limitations of traditional membrane-based probes. With no electrolyte, no oxygen consumption, and no flow dependency, it delivers stable, accurate measurements even in low-flow or static conditions.

It is especially suitable for applications where long-term stability, low maintenance, and reliable digital communication are critical.

وصف أجهزة الإرسال والاستشعار

Why Optical Dissolved Oxygen Measurement

Traditional electrochemical DO sensors require membranes, electrolytes, and frequent maintenance. This optical dissolved oxygen sensor adopts fluorescence measurement technology, providing a fundamentally different approach:

No membrane, no electrolyte, no polarization
عدم استهلاك الأكسجين أثناء القياس
Stable readings independent of flow velocity
Longer service life with significantly reduced maintenance cost

This makes it ideal for unattended operation and harsh field environments.

Dissolved O2 Sensor Features

Maintenance-Free Optical Technology

Membrane-free design with no electrolyte replacement
No polarization effect, no drift caused by oxygen consumption
Fluorescent cap is easy to replace when required

قياس دقيق ومستقر

Fast response time and excellent long-term stability
Minimal annual drift ensures consistent performance
Built-in temperature sensor with automatic temperature compensation

Designed for Field Reliability

Fully sealed IP68 housing for submersible installation
316L stainless steel + PPS body resists corrosion
Not affected by flow rate, bubbles, or low-velocity conditions

Digital Integration Ready

RS485 communication (Modbus-compatible)
Easy connection to PLC, SCADA, or upper-level control systems

Dissolved Oxygen Sensors Applications

Wastewater treatment (aeration basins, biological tanks)
المياه السطحية والرصد البيئي
Aquaculture and fish farming systems
مياه العمليات الصناعية
Municipal water and utility monitoring

Dissolved Oxygen Sensor Designed for Long-Term Operation

By removing consumable components and minimizing maintenance requirements, this dissolved oxygen sensor significantly reduces total cost of ownership while ensuring reliable data for process control and environmental compliance.

It is not just a sensor—it is a long-term monitoring solution.

معلمة أجهزة الإرسال والاستشعار

المعلمة	المواصفات
مبدأ القياس	Optical fluorescence
Dissolved Oxygen Range	0 ~ 20 mg/L or 0 ~ 200 % saturation
Temperature Range (Process)	0 ~ 45 ℃
ضغط التشغيل	≤ 0.3 MPa
دقة القياس	DO: ±0.3 mg/L or ±3 %Temperature: ±0.5 ℃
إشارة الإخراج	RS485
مواد الإسكان	316L Stainless Steel + PPS
فئة الحماية	IP68
Sensor Dimensions	Ø49.5 × 251.5 mm
طريقة التثبيت	Submersible
درجة الحرارة المحيطة	0 ~ 60 ℃
الرطوبة النسبية	< 90 % RH
طول الكابل	10 m standardUp to 100 m customizable

إنسترافا OEM/ODM

أدوات موثوقة. حلول تناسب تطبيقك.

تركز إنسترافا على تقديم حلول صناعية موثوقة من خلال المنتجات المنتقاة بعناية والتحسين القائم على التطبيقات والتخصيص المرن. نختار الأدوات التي أثبتت كفاءتها من الشركات المصنعة الموثوق بها لضمان جودة متسقة، ونعمل على تحسين الحلول بناءً على ظروف العمل الحقيقية لحل التحديات العملية، ونوفر تكوينات مصممة خصيصًا لتلبية احتياجات التطبيقات المحددة.

تساعد Instrava العملاء على تقليل المخاطر وتحسين الكفاءة وتحقيق نتائج يمكن الاعتماد عليها في البيئات الصناعية المعقدة من خلال الجمع بين الخبرة في الاختيار وفهم التطبيقات.

توصيات المنتجات ذات الصلة

جهاز إرسال ضغط ذكي لصناعة معالجة المياه، يتميز بإشارات رقمية بالكامل وشاشة LCD محلية عالية الوضوح.
