Interruptores de nivel
Interruptores de nivel de flotador de montaje lateral para control de nivel de líquidos industriales
Instrumentos curados Instrava — Through carefully selected industrial-grade sensing technologies, our float level switches deliver stable, reliable, and long-term liquid level control for demanding industrial environments.
Este side-mounted float level switch for liquid level control is designed for precise switching at defined liquid levels, ensuring safe operation in chemical, petroleum, marine, and storage systems.
✔ High pressure resistance
✔ Explosion-proof safety design
✔ Stable mechanical operation
Liquid Level Switches Description
Side-Mounted Float Level Switch Advantages for Industrial Applications
Reliable Side-Mounted Float Level Switch for Industrial Tanks
En side-mounted float level switch for tanks is engineered for accurate point level detection when liquid reaches a preset position, making it ideal for:
- Depósitos
- Transportation vessels
- Industrial process systems
It ensures consistent switching performance in repetitive operations.
Mechanical Float Level Switch Based on Lever and Magnetic Principle
Este float level switch with magnetic lever mechanism operates using:
- Buoyancy force
- Lever principle
- Magnetic switching action
This design ensures stable and repeatable ON/OFF control without electronic drift.
High-Pressure Explosion Proof Float Level Switch for Harsh Environments
Designed for extreme conditions, this explosion-proof float level switch for high-pressure systems supports:
- Pressure up to 10 MPa
- Temperature up to 350°C
- Exd IIC T4~T6 certification
Ideal para oil, gas, and chemical industries.
Maintenance-Free Side-Mounted Float Level Switch
With a robust mechanical structure, this maintenance-free float level switch offers:
- No electronic calibration required
- Larga vida útil
- Stable operation in repetitive cycles
Side-Mounted Float Level Switch Applications in Industrial Systems
Float Level Switch for Chemical and Petroleum Industry Tanks
Este side-mounted float level switch for chemical tanks and petroleum systems is widely used in:
- Tanques de almacenamiento de productos químicos
- Oil & fuel storage systems
- Refinery processing units
- Marine and ship ballast systems
Float Level Switch for High-Temperature Industrial Applications
With operating temperature up to 350°C, this high-temperature float level switch for industrial systems is suitable for:
- Steam systems
- High-temperature process tanks
- Thermal storage systems
Float Level Switch for Pump Control and Level Alarm
The system provides reliable liquid level ON/OFF switching for:
- Control de arranque/parada de la bomba
- Overflow protection
- Dry-run prevention
- High/low level alarms
Liquid Level Switches Parameter
| Parámetro | Especificación |
|---|---|
| Modelo | HMFS 413 |
| Installation Type | Side Mounted |
| Principio de medición | Float + Lever + Magnetic Switch |
| Control Range | ≤ 10 mm / 25–550 mm |
| Presión de funcionamiento | -0.1 to 10 MPa |
| Temperatura de funcionamiento | 0°C to 350°C |
| Output Capacity | 220VAC/DC, 150W |
| Adjustment Mode | Non-adjustable / Adjustable (Model dependent) |
| Explosion Proof Grade | Ex d IIC T4~T6 |
| Clasificación IP | IP65 |
| Medio | Liquids |
Instrava OEM/ODM
Instrumentos fiables. Soluciones que se adaptan a su aplicación.
Instrava se centra en ofrecer soluciones industriales fiables a través de productos cuidadosamente seleccionados, optimización basada en aplicaciones y personalización flexible. Seleccionamos instrumentos probados de fabricantes de confianza para garantizar una calidad constante, optimizamos soluciones basadas en condiciones de trabajo reales para resolver retos prácticos y ofrecemos configuraciones a medida para satisfacer las necesidades de aplicaciones específicas.
Combinando la experiencia en selección con la comprensión de las aplicaciones, Instrava ayuda a sus clientes a reducir riesgos, mejorar la eficacia y obtener resultados fiables en entornos industriales complejos.
What is a side-mounted float level switch and how does it work?
A side-mounted float level switch is a mechanical device that detects liquid level using a float connected to a lever and magnetic mechanism. When the liquid reaches a set point, the switch changes state to control or alarm the system.
Where are float level switches commonly used?
A float level switch for industrial liquid control is widely used in:
- Chemical tanks
- Petroleum storage systems
- Marine ballast tanks
- Industrial process vessels
Can float level switches work under high pressure and temperature?
Yes, this high-pressure float level switch (up to 10 MPa) y high-temperature float switch (up to 350°C) is designed for harsh industrial environments.
Is the side-mounted float level switch explosion-proof?
Yes, it is available with Ex d IIC T4~T6 explosion-proof certification, making it suitable for hazardous chemical and petroleum environments.
Does a float level switch require calibration or maintenance?
No frequent calibration is required. This mechanical float level switch operates with a simple physical mechanism, making it highly reliable and low-maintenance.
What makes side-mounted float level switches reliable?
Their reliability comes from:
- Simple mechanical structure
- Magnetic switching principle
- No complex electronics
- Strong resistance to harsh conditions
