Customized Supplier Magnetic Float Level Transmitter In China
Your trusted sourcing partner for magnetic float level transmitter in china—quality instruments at competitive prices.
Are you overwhelmed by too many conflicting quotes?
Are you worried about factory capabilities because tight project deadlines and heavy procurement tasks leave you no time to audit suppliers?
Are you wasting time researching because every factory claims their product is the best, thereby delaying your procurement schedule?
Instrava is here to help you solve your procurement challenges in China.
We serves a global clientele, including EPC contractors, OEM equipment manufacturers, procurement managers, distributors, traders, and engineering consultants. We provide curated product quotations from 3 pre-vetted factories
Standardized Supplier Qualification ProcessEvery manufacturing partner is evaluated through our standardized supplier qualification process before being included in the Instrava sourcing network. The assessment focuses on manufacturing capability, engineering expertise, quality control, delivery reliability, and long-term service support., helping our clients drastically save time on sourcing, screening, and supplier comparison.
Whether you are building new industrial production lines, upgrading and replacing legacy instruments, sourcing for wholesale trade, or requiring custom OEM production, we empower you to secure the most perfectly matched products.
Let’s collaborate for mutual success. With our customer-centric service, Instrava is your trusted procurement partner in China.
Magnetic Level Transmitter Selection Guide & Specifications Table
Sourcing a magnetic float level transmitter requires a systematic engineering approach. Critical evaluation factors include process media characteristics, operating parameters, measuring range, output signals, communication protocols, IP protection ratings, and mounting methods.
Note: Specifications may vary depending on manufacturer configuration and customization requirements. Please contact us for detailed technical confirmation.
Magnetic float level gauge technical specifications
| Parameter Item | Specifications | International Standard Options & Customization |
| Measuring Range | 200 – 6,000 mm ($7.87″ – 236″$) | Customizable (> 6,000 mm / 20 ft available upon request) |
| Medium Density & Wetted Materials | Density: $\ge 0.5\text{ g/cm}^3$ ($\ge 500\text{ kg/m}^3$) | Customizable
• Calibrated for Liquid-Liquid Interface (e.g., Oil-Water)
• Wetted Materials: 304 SS, 316L SS, 316Ti, Titanium, Hastelloy C-276, Monel, PTFE / PFA / PP Lining |
| Resolution / Accuracy | 5 mm ($1/5″$), 10 mm ($3/8″$), 20 mm ($3/4″$) | Customizable (High-precision continuous resolution options) |
| Signal Output & Protocols | • 4–20 mA DC (2-Wire)
• Resistance: 200 $\Omega/\text{m}$ (1/2″, 3/8″) | Customizable
• HART 7.0 Protocol
• RS485 Modbus RTU
• Foundation Fieldbus / PROFIBUS PA |
| Power Supply & Load | • Power: 16 – 30 VDC (24 VDC Nominal)
• Max Load: $500\ \Omega$ @ 24 VDC | Standard industrial loop-powered specs |
| Transmission Distance | > 1,000 m ($3,280\text{ ft}$) | Standard |
| Operating Pressure | PN2.5 – PN160 ($0.25 – 16\text{ MPa}$) | Customizable
• ASME/ANSI: Class 150, 300, 600, 900, 1500, 2500
• DIN/EN: PN10 to PN320 (Up to $32\text{ MPa}$) |
| Operating Temperature | • Process Temp: -40°C to 150°C
• Ambient Temp: -40°C to 85°C | Customizable
• Cryogenic: Down to -196°C (LN2/LNG)
• High-Temp: Up to 350°C / 450°C (Thermal Oil/Steam) |
| Float Ball Specifications | $\Phi 30\text{ mm}$ – $\Phi 120\text{ mm}$ | Customized based on pressure, density & temperature requirements |
| Process Connection | • Flange: 1.5″ to 6″ (DN40 – DN150)
* Standards: ASME B16.5, EN 1092-1, JIS B2220
* Rating: Class 150–1500 / PN10–PN160
• Thread: 1.5″ / 2″ NPT or BSPT (Downward)
• Small Thread: 1/2″, 3/8″ NPT (Upward) | Customizable (Custom flanges, Tri-Clamp for hygienic/sanitary applications) |
| Installation Angle | $\le \pm 25^\circ$ Vertical | Standard |
| Electrical Connection | M20×1.5, 1/2″ NPT Female, or 3-core shielded cable | Customizable (Cable gland specifications tailored to regional standards) |
| Ingress Protection (IP) | IP65 / IP67 | Customizable (IP68 submersible option for sumps/underground tanks) |
| Explosion-Proof & Safety | • Exia II CT6 Ga (Intrinsically Safe)
• Exd II CT6 Gb (Flameproof/Explosion-Proof) | International Certifications:
• ATEX / IECEx (CE Marked for European & Global Markets)
• SIL 2 / SIL 3 Functional Safety (IEC 61508) |
Expert Engineering & Certified Manufacturing: Custom Level Solutions for Any Scale
Through a rigorous, systematic vetting process of Chinese manufacturers, we partner exclusively with factories possessing 10 to 30 years of specialized manufacturing experience. Backed by engineering teams of over 15 experts, we are fully equipped to resolve complex process challenges and deliver fully customized product solutions tailored to your specifications.
Our partner facilities hold internationally recognized certifications, including CE, ATEX, IECEx, ISO 9001, and SIL 2/3, ensuring compliance with global market standards.
Whether your order is for 1 unit or 100 units, we are committed to delivering pre-vetted, high-quality industrial instrumentation every time.
“Finding a reliable supplier for custom Hastelloy C-276 level transmitters at PN80 rating used to be a major headache for our high-pressure reverse osmosis units. Instrava delivered exceptional engineering support from day one—their team carefully verified the float buoyancy calculations against our high-salinity brine density. The 4000mm transmitters arrived flawlessly packed in reinforced wooden crates with zero stem bending. After 6 months of continuous operation under harsh Gulf ambient conditions, the readings remain 100% stable with zero drift. Truly a top-tier curated sourcing experience.”-Mansoor（Procurement Director）
Magnetic Float Level Transmitter — Product Series Taxonomy(customized)
Driven by a mechanical float that moves with the fluid level and an internal reed switch/resistor chain, the magnetic float level transmitter excels at continuous liquid level and immiscible liquid-liquid interface measurements—making it a highly reliable, magnetically coupled contact-type instrument for harsh process environments.
| Product Series | Key Matrix Combination (Structure × Material × Function) | Primary Target Applications | Key Features & Advantages |
1. Standard Industrial Series | Top / Side Mounted + 304 SS / 316L SS + Standard 4–20mA / HART / Exd | Water treatment, fuel/diesel storage tanks, edible oils, general chemical storage | Cost-effective, robust 316L stainless steel construction, standard loop-powered 2-wire output. |
2. Anti-Corrosion Chemical Series | Top / Side Mounted + PTFE / PFA Lined / PP / PVDF + Corrosive Single Level / Exia | HCl, $H_2SO_4$, NaOH, aggressive acids, alkalis, electroplating, semiconductor chemical tanks | Complete fluoro-polymer barrier prevents metal contact, high chemical resistance against strong acids. |
3. Special Alloy & Extreme Process Series | Top / Side Mounted + Hastelloy C-276 / Titanium + High Pressure (PN80–PN280) / Exd | Desalination plants, wet chlorine, PTA reaction towers, offshore separators, high-salinity brine | Exceptional resistance to $Cl^-$ pitting, wet gas, and sour crude ($H_2S$); engineered for extreme pressures. |
4. Liquid-Liquid Interface Series | Top / Side Mounted + 316L SS / Hastelloy C-276 + Calibrated Dual-Density Float | Oil-water separators, extraction columns, solvent recovery, decanting tanks | Custom-weighted float calibrated to settle precisely at the boundary of two immiscible liquids. |
5. Deep Sump & Underground Series | Flexible Cable / Guided + 316L SS / PTFE Heavy Anchor + Extended Length (5–10 m+) | Underground storage tanks, deep drainage sumps, wastewater collection pits, petrol stations | Flexible cable probe eliminates rigid stem bending during shipping and installation in deep tanks. |
6. High-Temp & High-Pressure Series | Side-Mounted Bypass Chamber + Heavy-Wall SS316 / Hastelloy + High Temp ($>200^\circ\text{C}$) / High Pressure | Boiler drums, hydrogenation reactors, thermal oil tanks, high-pressure autoclaves | Features extended cooling necks, heavy-wall pressure chambers, and crush-resistant engineered floats. |
Comprehensive Industrial Applications
Robust magnetic float level transmitters engineered for diverse processing industries, harsh environments, and sanitary standards.
Petroleum Refining & Oil-Water Separation
In petroleum refineries and offshore platforms, magnetic float level transmitters monitor crude distillation column bottoms, flash drums, and storage tanks.
With dual-density calibrated floats, these sensors excel at measuring liquid-liquid interface boundaries—such as oil-water separation layers in electrostatic desalters and primary production separators.
Chemical Processing & Chlor-Alkali
Handling aggressive media such as hydrochloric acid (HCl), sulfuric acid (H₂SO₄), and wet chlorine gas requires extreme material performance.
Engineered with corrosion-proof PTFE/PFA linings, Hastelloy C-276, or Titanium, magnetic float transmitters prevent chemical degradation and deliver long-term reliability in acid reactors and chlor-alkali neutralization tanks.
Power Generation & High-Pressure Boilers
Thermal and combined-cycle power facilities rely on magnetic float transmitters across boiler drums, feedwater heaters, deaerators, and steam condensers.
Rated for pressures up to PN160 / PN320 and elevated temperatures, magnetic coupling operates smoothly without being affected by high-density saturated steam or thermal expansion.
LPG, LNG & Cryogenic Fuel Storage
Pressurized and cryogenic gas applications—such as Liquefied Petroleum Gas (LPG), LNG, and anhydrous ammonia—demand hermetic containment and strict flameproof safety.
Equipped with intrinsically safe (Exia II CT6) and explosion-proof (Exd II CT6) terminal enclosures, all electrical reed elements are completely isolated from pressurized hydrocarbon vapors.
Water Treatment & Seawater Desalination
In municipal wastewater plants, industrial zero liquid discharge (ZLD) systems, and seawater reverse osmosis (SWRO) facilities, transmitters face high chloride concentrations.
Corrosion-resistant metal alloys (such as Titanium or 316L SS) protect against seawater pitting and bio-fouling in high-pressure concentration towers, raw water intake pits, and chemical dosing tanks.
Pharmaceuticals & Food Processing
Hygiene and contamination control are critical in pharmaceutical synthesis, fermentation vessels, beverage blending, and edible oil refining.
Designed with polished 316L SS or PTFE wetted parts and Tri-Clamp sanitary process connections, these magnetic float transmitters support CIP/SIP (Clean-In-Place / Steam-In-Place) procedures without dead legs.
Mining & Hydrometallurgy (HPAL)
Metal extraction processes—such as high-pressure acid leaching (HPAL) for battery-grade nickel and cobalt—involve hot, highly abrasive, and acidic mineral slurries.
Heavy-duty magnetic float transmitters manufactured with Titanium or Hastelloy wetted components withstand extreme acid corrosion and harsh mechanical slurry environments.
Pulp, Paper & Textile Dyeing
Pulp bleaching towers, liquor recovery boilers, and textile dyeing vats utilize strong bleaches, caustic solutions, and organic dyes under elevated temperatures.
Magnetic float transmitters penetrate through dense surface foam and floating fibers, ensuring continuous, drift-free liquid level tracking where optical sensors get blinded.
Magnetic Float Level Gauge Ordering Matrix
Interactive sizing & configuration tool for liquid level / interface monitoring in Oil & Gas, Chemical, Power, and Sanitary process plants.
Flange Connection
Down Flange/Thread
Up Flange/Thread
External Pipe Cage
Sanitary / Food & Pharma
Ambient / Normal
Medium Temp
High Temp (Special Indicator)
Extreme Temp (Ceramic Flags)
(Standard Reed Chain)
(High Precision)
(Economical)
(Continuous 1mm Precision)
Intrinsically Safe
Flameproof / Explosion-Proof Enclosure
Request Official B2B Engineering Quotation
Selecting items in the spec matrix above will auto-generate your detailed engineering payload below.
FAQ For Purchasing Magnetic Float Level Transmitter
What is the process for purchasing magnetic float level gauge from Instrava supplier？
1. Inquiry (We will respond to your inquiry within 24 hours to confirm specifications and initiate the process.)
2. Quotation (Quotation timelines vary based on the project type and your specific requirements. Standard stock items are quoted within one day, while special orders require three days or a mutually agreed-upon timeframe.)
3. Product Selection (We will present 3–5 product options and pricing for your approval. During this stage, we verify the manufacturer’s production capabilities and relevant national certifications.)
4. Contract, Prepayment, and Production (A 40% prepayment is required to initiate production at a qualified facility. For stock items, we promptly arrange for product testing and packaging.)
5. Interim Payment (Upon successful completion of production and quality inspection, the next 50% of the total amount is due. For stock items, this payment is made after packaging is complete.If the transaction amount does not exceed $50,000, the remaining 60% is paid.)
6. Shipment (You may designate a freight forwarder, or we can arrange shipping for you.)
7. Receipt of Goods (Our Quality Guarantee: When your cumulative order value reaches $50,000, you pay the remaining 10% only after receiving and verifying the product quality. We let our quality do the talking.)
8. After-Sales Service (We actively address and resolve issues through both online and offline channels. We place great importance on after-sales support, as it reflects our responsibility and reputation—the foundation of Instrava’s long-term growth.)
What are the advantages of buying products from Instrava ?
Buying from Instrava gives you the best of both worlds—the direct-from-source pricing of a factory, combined with the professional service, product range, and risk mitigation of an elite sourcing partner. Here is how we deliver value to your business:
Unbiased Market Curation (More Choices & Better Prices): Unlike single factories that only praise their own capacity, or traditional trading companies restricted by personal connection networks, we evaluate the entire Chinese manufacturing landscape. We benchmark and source from multiple verified factories to secure the most competitive pricing and the exact product specifications you need.
100% Transparency (Your “Brain” in China): We never hide behind the veil of being a “fake manufacturer.” We act as your transparent, in-country purchasing department. You always know exactly who is producing your goods, how much they cost, and what the real lead times are.
Uncompromised Quality & Risk Mitigation: Our business is built on long-term partnerships, not one-off high-profit transactions. We perform strict, independent quality control from your perspective before shipment, protecting you from post-purchase defects and communication breakdowns.
Streamlined Communication & Service: No more dealing with slow, production-centric factory service. We provide a single, highly responsive point of contact that manages the entire supply chain—from negotiation and quality checks to shipping logistics—saving you time and reducing headaches.
What types of industrial automation instruments products can you purchase from Instrava?
Level gauge, flowmeter, transmitter, level switch, Gas Alarm Controllers etc.
How to ensure the reliability of the purchased products?
Our customer-centric philosophy prioritizes their procurement needs.
1. Initially confirm the manufacturer based on product pricing and the strength and qualifications of the production factory.
2. Verify the manufacturer’s production environment through video and on-site inspections to check the compliance of the entire product manufacturing process.
3. Ensure post-production product testing and retain data and video evidence from the verification process(testing and verification methods vary depending on the product).
How does Instrava ensure product protection and physical safety during cross-border shipping?
Firstly, we confirm the packaged products with the factory (different products require different packaging and shipping methods. Heavy equipment and bulk shipments are securely secured within sea freight containers using custom-designed engineering steel frames, heavy-duty multi-layer wooden crates, and industrial-grade vacuum rust-proof bags. Precision instruments are protected against impacts and maintained in a stable position; the factory has extensive experience in this area. Custom labels are affixed to the outer packaging).
Secondly, we maintain communication with the freight company to confirm the condition of the goods and advise them to handle the loading and unloading processes with care.
What warranty policies and after-sales technical support does Instrava offer to international customers?
1. Instrava offers a comprehensive 12 to 24-month warranty (specific warranty period depends on the product line), covering all manufacturing and component defects.
2. When online technical support is needed, customers can connect with factory engineers online. Real-time guidance is provided for installation, on-site calibration (for instruments), and commissioning. When on-site engineer support is needed, we will arrange for an engineer to visit the site.
3. In the event of component issues, we will ship replacement parts via international express delivery (DHL/FedEx) to minimize your project downtime.
4. Whether a product requires replacement or repair will be clearly stated in the purchase contract.
Why Trust Instrava?
We select manufacturers from a neutral, impartial standpoint, always with your best interests in mind.
Our very existence depends on helping you source the products that are the perfect fit for your needs.
Based in China, we are able to conduct on-site inspections of production environments and product quality firsthand.
We help you avoid intermediaries posing as factories.
We facilitate smoother after-sales support, eliminating time zone issues and the delays often associated with dealing directly with factories.
Our multilingual team ensures effective communication.
For a trading startup, every interaction with a client is a precious opportunity—a sign that you are willing to place your trust in us and give us the chance to prove ourselves.
In the digital age, while information is easily accessible, misconceptions often cloud the trust between people.
Instrava relies entirely on trust; it is our core philosophy and the foundation of our existence in society. It is the fundamental basis for our long-term growth and our commitment to serving the community.
Please place your trust in us.
