Purchase from Chinese suppliers 220KV 230KV Oil-Immersed Power Transformers
Instrava understands that 110kV~230kV power transformers are critical assets, and grid failures are absolutely unacceptable. Therefore, we work with you to make the procurement decision.
As your trusted partner, we carefully evaluate reliable manufacturing plants and verify their qualifications by visiting and inspecting certified transformer factories on-site.
Quotes for large transformer projects are available in approximately 7 days.
Production cycles are between 60 and 90 days.
Transformer Description
China’s transformer manufacturing core technologies are internationally leading/first-of-its-kind.
Transformer Fault Active Defense Technology (Trip):A world first, deeply integrating partial discharge monitoring with relay protection, achieving a leap from “post-incident remediation” to “automatic tripping before explosion.” Verified with zero false tripping after 1.8 million interference tests, the technology has been identified as internationally leading and is compatible with 110kV and above equipment.
500kV Industrial Rectifier Transformer Direct Step-Down Solution: The world’s first such product, breaking through the traditional “220kV + step-down substation” model, achieving direct step-down of 500kV to over 1000V power supply, eliminating intermediate links, improving system efficiency by approximately 0.4%, and significantly reducing infrastructure costs.
Solid-State Transformer Engineering Applications: Targeting high-frequency scenarios such as AI data centers, achieving a breakthrough from laboratory to engineering applications, possessing high-frequency, miniaturized, and excellent power quality control capabilities, with some indicators even surpassing previous performance levels.
Ultra-high voltage intelligent monitoring and digital twin operation and maintenance: Overcoming core technological barriers in the 1000kV ultra-high voltage field, integrating online diagnostics, 5G smart factory full-process traceability, and digital twin operation and maintenance systems to achieve precise control throughout the entire lifecycle.
Breakthrough Innovation in China’s Special High-Voltage Step-Down Transformer
As the world’s first station service transformer to directly step down from 750 kV to 10 kV, this product has overcome a series of industry challenges, including insulation design under ultra-high turns ratios, electric field balancing, and lightweight structure. It has successfully set five world records in the field of station service transformers: largest station service capacity, highest voltage level, highest turns ratio, most winding turns, and highest transmitted overvoltage. This provides crucial equipment support for the intensive and efficient construction of converter stations.
The overvoltage transmitted between the high and low voltage windings reaches 1054%, exceeding the insulation level of the low-voltage winding itself by more than 10.5 times. A series of technical measures adopted provide a solid guarantee for the safe operation of the equipment.
Transformer Parameter
|
Phase
|
Three
|
|
Coil Number
|
2
|
|
Usage
|
Power
|
|
Coil Structure
|
Pie coil
|
|
Rated Primary Voltage
|
110
|
|
Rated Secondary Voltage
|
11
|
|
Power
|
10MVA
|
|
Standard
|
IEC60076
|
|
Warranty
|
2 Years
|
|
Cooling Method
|
ONAN
|
|
Frequency
|
50 / 60Hz
|
|
Vector Group
|
YNd11
|
|
Material
|
Copper / Aluminium
|
|
Application
|
Mining
|
|
Impedance
|
10.5
|
|
Tapping Ranges
|
±8*1.25%
|
| Main Technical Parameters for oil-immersed power transformer | ||||||||
| Rated Power(kva) | High Voltage(kv) | H.V.Tap range | Low Voltage(kv) | Connection symbol | Short Circuit Impendence | No-load loss(kw) | On-load loss(kw) | No-load current(%) |
| 6300 | 63 66 69 110 132 138 220 |
±8x 1.25% |
6.3 6.6 10.5 11 33 69 |
YNd11 YNyn0 others |
10-14 | 9.4 | 34 | 0.63 |
| 8000 | 11.2 | 40.4 | 0.63 | |||||
| 10000 | 13.1 | 47.6 | 0.75 | |||||
| 12500 | 15.4 | 56.5 | 0.53 | |||||
| 16000 | 18.5 | 69.5 | 0.49 | |||||
| 20000 | 21.8 | 84.2 | 0.49 | |||||
| 25000 | 25.6 | 99.5 | 0.4 | |||||
| 31500 | 30.4 | 120 | 0.4 | |||||
| 40000 | 36.2 | 140.3 | 0.39 | |||||
| 50000 | 42.6 | 174.3 | 0.39 | |||||
| 63000 | 52 | 210 | 0.39 | |||||
| 75000 | 60 | 238 | 0.49 | |||||
| 90000 | 69 | 274 | 0.49 | |||||
| 120000 | 85 | 328 | 0.46 | |||||
| 150000 | 101 | 385 | 0.42 | |||||
| 160000 | 105 | 404 | 0.42 | |||||
| 180000 | 115 | 436 | 0.42 | |||||
| 240000 | 144 | 539 | 0.4 | |||||
