Magnetic Float Level Switch for Reliable Level Control
The Instrava magnetic float level switch is designed for reliable point level detection and automatic control of pumps, motors, and other electrical equipment in industrial applications. Using a magnetic float and reed switch structure, it provides stable on/off switching independent of the physical or chemical properties of the medium.
With a simple structure, long service life, and explosion-proof design, this level switch is suitable for harsh operating environments and critical level control tasks.
Key Benefits
-
Stable and reliable switching with long service life
-
Independent of medium conductivity, viscosity, or chemical properties
-
Direct control of pumps and contactors without additional circuits
-
Suitable for high-pressure, high-temperature, and hazardous areas
-
Standard, customized, and OEM configurations available
Liquid Level Switches Description
Why Choose This Magnetic Float Level Switch
In many industrial tanks and vessels, continuous level measurement is not required. What matters is reliable level control to protect equipment and ensure safe operation. The Instrava magnetic float level switch is designed to deliver dependable switching performance even in challenging process conditions.
For plant operators, engineers, and system integrators, it offers:
-
Minimal maintenance and simple installation
-
Reliable operation in contaminated or corrosive media
-
Clear upper and lower level control logic
-
Long-term stability with low failure rates
Magnetic Float Level Switch Typical Applications & Use Scenarios
This magnetic float level switch is widely used in industrial level control applications:
-
Water & Wastewater Systems
Automatic pump start/stop control in tanks and sumps. -
Chemical & Petrochemical Processing
Level limit protection in pressure vessels and storage tanks. -
Power & Energy Systems
Level control in auxiliary tanks and process containers. -
Industrial Equipment & OEM Systems
Integration into packaged equipment and control skids.
Liquid Level Switches Parameter
Magnetic Float Level Switch Technical Specifications
| Parameter | Specification |
|---|---|
| Maximum Insertion Depth | 5 m (longer length customizable) |
| Control Scope (Max) | L – 120 mm |
| Control Scope (Min) | 50 mm (below 50 mm customizable) |
| Medium Density | ≥ 0.65 g/cm³ |
| Working Pressure | PN2.5 ~ PN160 |
| Working Temperature | –40 ~ +150 °C |
| Float Diameter | Ø28 ~ Ø120 mm (depending on pressure and density) |
| Installation Type | Flange: DN40 ~ DN150 |
| Flange Standard | HG/T20592–2009 |
| Thread Connection | G2” |
| Other Installation Methods | Available on request |
| Maximum Switching Frequency | ≤ 1 × 10⁵ operations |
| Switching Error | ±8 ±2 mm |
| Working Power Supply | 220 VAC / 380 VAC |
| Maximum Switch Voltage | ≤ 250 VAC |
| Maximum Switch Current | 5 A |
| Installation Angle Tolerance | ≤ ±25° |
| Wiring Box | M20 × 1.5 female thread |
| Protection Grade | IP65 |
| Explosion-Proof Rating | Exd II CT6 Gb |
