Edge Gateway – 5G Industrial Intelligent Edge Gateway
Instrava Curated Instruments: Industrial Edge Gateway Built for the Connected Future
Instrava Curated Instruments présente une nouvelle génération d'instruments de mesure. Edge Gateway engineered to bridge industrial assets with modern digital infrastructure. Designed for high-performance edge connectivity, this 5G industrial edge gateway combines ultra-reliable communications, edge computing intelligence, and seamless protocol interoperability in one rugged platform.
Built on a domestic industrial-grade architecture, this intelligent gateway supports 5G dual-mode connectivity, Wi-Fi 6, Gigabit Ethernet, LoRa, Bluetooth 5.2, RedCap, and optional GPS/BeiDou positioning, enabling secure and resilient connectivity across diverse industrial environments. Whether deployed for industrial automation, smart manufacturing, AGV fleets, robotic inspection, or smart healthcare, it delivers the speed, reliability, and flexibility required for real-time operations.
With built-in support for OPC UA, MQTT, Modbus TCP/RTU, SQL, IEC 61850, and multiple PLC/CNC protocols, this industrial IoT edge gateway acts as a powerful bridge between legacy equipment and cloud-based analytics platforms. It transforms isolated field devices into connected, intelligent assets—accelerating digital transformation while preserving existing infrastructure investments.
Edge Gateway Description
Why Choose This Industrial Edge Gateway?
Ultra-Reliable Connectivity for Mission-Critical Applications
Le présent 5G edge gateway for industrial IoT is designed to maintain uninterrupted communications in demanding environments. With support for dual-transmit selective-receive technology, it achieves network reliability of ≥99.99% and ultra-low latency of ≤12ms, making it ideal for real-time control, remote monitoring, and autonomous systems.
Key communication advantages include:
- 5G NR with support for Release 16 and Release 17 features
- Dual-band Wi-Fi 6 (2.4GHz / 5.8GHz) for high-density wireless environments
- En option LoRa, Bluetooth 5.2, StarFlash, and RedCap connectivity
- Gigabit Ethernet with flexible WAN/LAN configuration
- En option GPS/BeiDou positioning for mobile and remote deployments
This combination ensures continuous, high-speed data transmission across fixed, mobile, and distributed industrial networks.
Edge Intelligence for Industrial Digital Transformation
More than a communication device, this industrial edge computing gateway enables local data processing, intelligent decision-making, and seamless cloud integration.
Advanced Edge Computing Capabilities
- Quad-core ARM Cortex-A55 processor (≥1.8GHz)
- Intégré 1 TOPS NPU for AI-enabled edge analytics
- Soutien Docker containers for flexible application deployment
- Local real-time data analysis and event processing
- Breakpoint resume for reliable data continuity during network interruptions
Broad Industrial Protocol Compatibility
Southbound connectivity supports data acquisition from:
- Automates programmables
- CNC machines
- Compteurs d'énergie
- Sensors and field instruments
Northbound connectivity supports integration with:
- MQTT brokers and cloud platforms
- OPC UA servers
- SQL Server and MySQL databases
- Modbus TCP systems
- SCADA, MES, and enterprise platforms
This makes it an ideal OPC UA edge gateway, Modbus gateway, et industrial protocol converter for modern smart factories and process automation systems.
Edge Gateway Parameter
| CPU | Quad ARM Cortex-A55 2.0GHz |
| GPU | Mali G52 2EE, OpenGL ES 1.1/2.0/3.2, OpenCL 2.0 & Vulkan 1.1 |
| NPU | 1 TOPS for lightweight AI |
| Mémoire | 2GB |
| Built-in storage | 8GB |
| Cellular Interface | |
| Modem | 1 × LTE Cat4 or 1/2 × 5G NR SA/NSA |
| Number of Antennas | 2 (LTE version) or 4/8 (NR version) |
| Connector | SMA-K |
| SIM | 2 |
| Wireless Interface | |
| Standards | 802.11b/g/n/ac/ax, AP or station modes |
| Frequency Bands | 2.4 GHz & 5 GHz |
| Vitesse | 583Mbps |
| Sécurité | WEP, WPA, WPA2 |
| Cryptage | 64/128 AES, TKIP |
| Antennas | 2 |
| Connector | SMA-K |
| Star Flash | Soutien |
| Lora | Soutien |
| GNSS Interface | |
| Number of Antennas | 1 |
| Connector | SMA-K |
| Peripheral Interface | |
| Ethernet | 4 x RJ45 10/100/1000Mbps adaptive (1 of which supports WAN, LAN switching) |
| Serial | 1 × RS-232/RS-232 + 1 × RS-485 serial port |
| USB | 1 x USB2.0 |
| TF Card | 1 |
| HDMI | 1 |
| Extension interface | Extendable interface module Z4-EXT |
| Logiciel | |
| Auto Fail-over | Between: 2 Cellulars, Cellular and WAN, Cellular and Wi-Fi (station mode), WAN and Wi-Fi (station mode) |
| Network Protocols | PPP, PPPoE, TCP, UDP, DHCP, ICMP, NAT, HTTP, HTTPs, DNS, ARP, NTP, SMTP, Telnet, SSH, DDNS, etc. |
| Network | APN, VPDN, VLAN, QoS |
| Routing | Static Routing, Policy routing, RIP, OSPF and BGP, etc |
| Firewall | NAT, PAT, DMZ, Port Forword, IP/Domain/MAC Filter, Access Control List |
| Attack Prevention | DDOS prevention, Anti port scanning |
| VPN | PPTP/L2TP/GRE/IPSec/OpenVPN/DMVPN/WireGuard |
| Ipsec Encryption | DES, 3DES, AES128, AES192, AES256 |
| OpenVPN Encryption | BF-CBC, DES-CBC, RC2-CBC, DES-EDE-CBC, DES-EDE3-CBC, DESX-CBC, RC2-40-CBC, CAST5-CBC, RC2-64-CBC, AES-128-CBC,AES-192-CBC, AES-256-CBC, SEED-CBC |
| Remote Management | HTTP, Telnet, SSH, SMS, SNMP V1/V2/V3, SNMP TRAP, Hongdian Wedora Cloud Platform |
| Serial Ports Function | Transparent, Modbus RTU, etc |
| Protocole industriel | |
| Common Protocols | OPC-UA Client&Server, BACNet/IP Client&Server, Modbus RTU/TCP/ASCII, Modbus Master, BACnet/IP, Ethernet/IP,IEC101/104, IEC61850-modbus, etc. |
| Intégration dans le nuage | MQTT, HTTPS, Hongdian HMP, TCP/UDP, etc |
| Configuration Tool | HDGatewayManager |
| Power Supply and Consumption | |
| Connector | 2 pin socket |
| Tension d'entrée | +9V~+48V DC |
| Consommation électrique | Idle: 400mA@12V DC, Data transceiving: 1.5A@12V DC |
| Others | |
| Reset Button | Oui |
| Hardware Watchdog | Oui |
| LED Indicators | 6 indicators for PWR, WLAN, NET1, SIG1, DATA/NET2, LORA/SIG2 |
| Physical Characteristics | |
| Protection contre les infiltrations | IP30 |
| Housing & Weight | Metal, 1060g |
| Dimension | 170 × 136.2× 51mm |
| Installations | Desktop, wall mounting and DIN rail mounting |
| Température de fonctionnement | -35 ~ +75℃ |
| Température de stockage | -40 ~ +85℃ |
| Humidité relative | 95% |
Z4-ExBox Expansion Box
| Inputs/Outputs | |
| VCC-OUT | 1 voltage output, voltage source is the same as the input. |
| DI | 4 digital input channels (low-level input: 04.5V, high-level input: 636V). |
| Sorties relais | 2 relay outputs (3A 250VAC/30VDC). |
| RS-485 | 6 RS-485 interfaces (default baud rate 115200bps). |
| AI | AI1、AI2（4~20mA），AI3、AI4（0~5V） |
| CAN | 1 CAN interface. |
| GPIO | 4 GPIO channels (output 0-3.3V). |
| Expansion Interface | 1 2×6pin 2.54mm pitch expansion module board interface. |
| Consommation électrique | |
| Typical Power Consumption | 3.3V average current 40mA, 5V average current 86mA. |
| Environnement opérationnel | |
| Température de fonctionnement | -30℃ to +75℃ |
| Température de stockage | -40℃ to +85℃ |
| Constant Humidity | +45℃, 95% RH, 24h |
| Alternating Humidity | Temperature/Humidity: +25~+55℃ / 95% RH, 24 hours. |
| Physical Dimensions | |
| Dimensions | 136.2 × 170× 51mm |
| Poids | 950g. |
Instrava OEM/ODM
Des instruments fiables. Des solutions adaptées à votre application.
Instrava se concentre sur la fourniture de solutions industrielles fiables grâce à des produits soigneusement sélectionnés, à une optimisation axée sur les applications et à une personnalisation flexible. Nous sélectionnons des instruments éprouvés auprès de fabricants de confiance afin de garantir une qualité constante, nous optimisons les solutions en fonction des conditions de travail réelles afin de résoudre les problèmes pratiques, et nous fournissons des configurations sur mesure pour répondre aux besoins d'applications spécifiques.
En combinant l'expertise en matière de sélection et la compréhension des applications, Instrava aide ses clients à réduire les risques, à améliorer l'efficacité et à obtenir des résultats fiables dans des environnements industriels complexes.
Instrava conçoit la bonne voie pour numériser vos opérations - des instruments hérités aux systèmes connectés et axés sur les données.
Recommandations de produits connexes
What is an Edge Gateway and why is it important in industrial IoT?
An Edge Gateway is a device that connects field instruments, PLCs, and legacy systems to cloud platforms. It processes data locally, reduces latency, and minimizes bandwidth usage. In industrial IoT (IIoT), it plays a critical role by enabling real-time decision-making, protocol conversion (e.g., Modbus, HART, OPC UA), and secure data transmission without replacing existing equipment.
Can an Edge Gateway connect legacy instruments to the cloud without replacing them?
Yes, one of the main advantages of an Edge Gateway is brownfield integration. It allows legacy instruments using protocols like 4–20mA, Modbus RTU, or HART to be digitized and connected to cloud systems. This avoids costly system replacement and enables gradual digital transformation with minimal downtime.
What protocols are typically supported by an industrial Edge Gateway?
Most industrial Edge Gateways support multiple protocols to ensure compatibility across devices. Common southbound protocols include Modbus RTU/TCP, HART, Profibus, and CAN. Northbound communication often includes MQTT, HTTP/HTTPS, OPC UA, and REST APIs. This multi-protocol capability ensures seamless data flow from field devices to cloud platforms.
How does an Edge Gateway improve data security in IIoT systems?
Edge Gateways enhance security by processing sensitive data locally and reducing direct exposure of field devices to the internet. They typically include features such as data encryption (TLS/SSL), firewall protection, VPN support, and device authentication. This layered security architecture helps prevent unauthorized access and cyber threats.
How many Edge Gateways are needed in a factory deployment?
The number of Edge Gateways depends on factors such as device count, communication protocols, data volume, and physical layout. A typical deployment may use one gateway per production line, per workshop, or per 50–200 devices. Network segmentation, redundancy requirements, and real-time processing needs also influence the final architecture.
What is the difference between an Edge Gateway and a standard IoT gateway?
While both connect devices to the cloud, an Edge Gateway provides advanced local computing capabilities such as data filtering, preprocessing, and analytics. Unlike basic IoT gateways, edge gateways can execute logic, reduce cloud dependency, and support real-time industrial control scenarios, making them more suitable for complex industrial environments.
