75 KVA Dry Type Isolation Transformer
Instrava Curated Transformer — Reliable Power Isolation and Protection for Modern Electrical Systems
At Instrava, we go beyond simply supplying transformers. Through our Curated Transformer approach, we carefully evaluate and select proven power distribution technologies from trusted manufacturers, ensuring dependable performance, enhanced power quality, and long-term operational confidence.
The 75 KVA Dry Type Isolation Transformer is designed to provide safe electrical isolation and efficient voltage transformation from 480V Delta to 208Y/120V Wye, making it an ideal solution for commercial, industrial, institutional, and mission-critical power systems.
Featuring a dry-type, oil-free design and harmonic mitigating capabilities, this transformer helps improve power quality, reduce harmonic distortion, protect sensitive equipment, and enhance overall system reliability. Manufactured to ANSI, IEEE, CSA, and DOE standards and available with UL, cUL, CSA, SGS, and CE certifications, it delivers a trusted solution for modern facilities requiring clean and stable power distribution.
Transformer Description
Why Choose a Dry Type Isolation Transformer?
Complete Electrical Isolation for Enhanced Safety
The transformer provides galvanic isolation between the primary and secondary windings, helping protect equipment and personnel from electrical disturbances, ground faults, and unwanted voltage transients.
Electrical isolation helps:
- Improve system safety
- Reduce electrical noise
- Minimize ground loop problems
- Protect sensitive electronic equipment
- Enhance overall power quality
Harmonic Mitigating Design
Modern facilities often contain nonlinear loads such as:
- Variable Frequency Drives (VFDs)
- UPS Systems
- Data Center Equipment
- LED Lighting Systems
- Automation Equipment
- Computer Networks
These loads generate harmonics that can negatively impact electrical systems.
The Harmonic Mitigating Isolation Transformer (HMT) is specifically designed to reduce harmonic currents and improve power quality, helping increase equipment reliability and reduce premature failures.
Ideal 480V to 208Y/120V Voltage Conversion
The transformer converts 480V Delta power to a 208Y/120V Wye system with neutral, providing flexible power distribution for:
- Three-phase equipment
- Single-phase loads
- Office systems
- Lighting circuits
- IT infrastructure
- Commercial appliances
Dry-Type Oil-Free Construction
Unlike liquid-filled transformers, dry-type transformers eliminate the risks associated with insulating oil, including:
- Fire hazards
- Oil leaks
- Environmental contamination
- Additional maintenance requirements
This makes them especially suitable for occupied buildings and environmentally sensitive installations.
High Reliability and Low Maintenance
Built using premium electrical steel cores and precision winding technology, the transformer delivers dependable long-term operation with minimal maintenance requirements.
Compliance with North American Standards
Designed to meet ANSI, IEEE, CSA/CAN, and DOE requirements, the transformer provides confidence for engineers, contractors, utilities, and facility operators throughout North America.
Engineered for Critical Applications
The 75 KVA Dry Type Isolation Transformer is widely used wherever clean power, electrical isolation, and harmonic mitigation are required.
Data Centers
Provides isolated and conditioned power for servers, network switches, UPS systems, and mission-critical IT infrastructure.
Commercial Buildings
Supports offices, retail facilities, hotels, and mixed-use developments requiring reliable 208Y/120V distribution systems.
Healthcare Facilities
Ensures safe power distribution for medical equipment, laboratories, imaging systems, and critical patient care environments.
Educational Institutions
Provides dependable power for classrooms, research laboratories, computer centers, and campus infrastructure.
Industrial Automation Systems
Protects PLCs, automation controllers, VFDs, process control systems, and sensitive manufacturing equipment.
Renewable Energy Installations
Suitable for battery energy storage systems (BESS), solar energy projects, and distributed generation systems requiring electrical isolation and voltage conversion.
Optimized Solutions for Every Facility
At Instrava, we do more than supply transformers.
Our Optimized Solutions approach helps customers:
- Select the proper transformer size
- Reduce harmonic distortion
- Improve power quality
- Enhance system reliability
- Meet electrical code requirements
- Lower long-term operating costs
The result is a transformer solution tailored to real-world operating conditions.
Transformer Parameter
| Parameter | Specification |
|---|---|
| Product Name | Dry Type Isolation Transformer |
| Transformer Type | Harmonic Mitigating Isolation Transformer |
| Rated Power | 75 KVA (Custom Capacities Available) |
| Primary Voltage | 480V Delta |
| Secondary Voltage | 208Y/120V Wye with Neutral |
| Connection Type | Dyn11 or Customized |
| Phase Configuration | Three Phase |
| Frequency | 50Hz / 60Hz |
| Electrical Isolation | Full Galvanic Isolation |
| Harmonic Mitigation | Yes |
| Cooling Method | Natural Air Cooling |
| Insulation Type | Dry Type, Oil-Free |
| Application Voltage Class | 600V and Below |
| Standards | ANSI, IEEE, CSA/CAN, DOE |
| Certifications | UL, cUL, CSA, SGS, CE |
| Installation Environment | Indoor Industrial and Commercial Applications |
| Available Capacity Range | Customizable |
