China Supplier Power Three Phase Pad Mounted Transformer
As a strategic global supplier, rather than a single-product-line manufacturer, Instrava’s core value lies in our exceptional product selection.
Whatever your project’s customization requirements, we can provide solutions, leveraging the vast Chinese manufacturing market.
Our products meet global export certifications such as UL, CSA, IEC, IEEE, CE, and TUV.
Quotation time: 1-3 work days for standard voltage and functional projects; 3-7 work days for special projects (high voltage, customized functions).
Delivery time: 60-90 days (depending on quantity and project requirements).
Transformer Description
Compact Structural Design & Multi-Grid Application
When sourcing distribution-class infrastructure for our elite portfolio, Instrava prioritizes products built on advanced spatial engineering and architectural flexibility:
-
High-Efficiency “Combined Transformer” Design: This transformer series utilizes a highly integrated structural footprint that drastically reduces total equipment volume compared to traditional substations. This compact, low-profile layout is engineered specifically for city load centers, enabling installation directly alongside heavy consumer loads to dramatically reduce low-voltage cable run losses and elevate municipal power quality.
-
Dual Loop & Radial Feed Flexibility: Built to support both loop feed (ring network) and radial feed (terminal) configurations. This allows engineers to deploy the same high-performing asset in high-reliability redundant urban rings or as a dedicated point-of-use step-down unit in industrial branch systems.
-
Versatile Infrastructure Integration: Engineered for continuous outdoor deployment across a wide range of modern energy fields. It integrates seamlessly with outdoor overhead line transitions, underground buried cable networks, high-voltage switchgear, and smart grid transmission sectors, as well as demanding utility applications like transit railways, solar farms, and wind energy plants.
Absolute Safety, Thermal Resilience & Lifespan Integrity
Every pad-mounted unit selected for the Instrava power lineup undergoes rigid construction vetting to guarantee continuous performance in public or high-load spaces:
-
Fully Sealed & Tamper-Resistant Insulation: Features a fully sealed, dead-front insulated tank structure that completely encloses all live high-voltage and low-voltage terminals. This airtight layout shields internal components from environmental humidity and dust, preventing insulation breakdown while providing absolute personal safety for operators, field service technicians, and the general public.
-
Low Temperature Rise & Overload Capability: Built with premier thermal materials and high-grade mineral insulation oil that exhibit superior heat dissipation under strenuous cyclic loading. Its low temperature-rise engineering grants the transformer excellent continuous overload capability, allowing it to withstand sudden demand spikes from heavy machinery or variable renewable energy generation.
-
Low-Loss, Low-Noise Acoustics: The magnetic core is precisely bound to minimize magnetostriction and reduce background acoustic hum to ultra-low levels, making these units fully compliant with strict municipal noise codes. Advanced core and copper winding alignment minimizes total no-load and load losses, maximizing long-term utility return on investment (ROI).
Transformer Parameter
| Pad Mounted Transformer | ||||
| Rated Power (KVA) | High Voltage (KV) | Low Voltage (V) | Loss (W) | |
| No-load Loss (W) | On-load Loss (W) | |||
| 75KVA |
34.5KV/
19.92KV/
13.8KV/
79.57KV/
13.2KV/
7.62KV/
12.47KV/
7.2KV
or others
|
240V
480V
277V
600v
347V
|
180 | 1250 |
| 112.5KVA | 200 | 1500 | ||
| 150KVA | 280 | 2200 | ||
| 225KVA | 400 | 3050 | ||
| 300KVA | 480 | 3650 | ||
| 500KVA | 680 | 5100 | ||
| 750KVA | 980 | 7500 | ||
| 1000KVA | 1150 | 10300 | ||
| 1200KVA | 1320 | 12120 | ||
| 1500KVA | 1640 | 14500 | ||
| 2000KVA | 2160 | 20645 | ||
| 2500KVA | 2680 | 27786 | ||
| 3000KVA | 3300 | 30300 | ||
| 3750KVA | 4125 | |||
Instrava OEM/ODM
Tailored Sourcing & Customization: Getting You the Exact Product You Need
As your trusted supplier and sourcing partner, we bridge the gap between your custom requirements and China’s vast manufacturing capabilities.
Finding the right product in a massive supply chain can be challenging. That is where we step in.
As a curated industrial supplier, our core value is simple: we stand in your shoes to help you procure the most optimal products. Whether you are an EPC contractor needing specialized technical compliance, an OEM equipment manufacturer looking for custom branding, or an industrial distributor/trader seeking competitive edge, we customize and tailor products to fit your exact procurement needs.
How We Customize to Fit Your Procurement Needs
For EPC Contractors & Engineers: We custom-configure instruments and devices to match your precise datasheets—tailoring process connections, exotic materials, signal protocols, and managing third-party calibration and testing so you get project-ready solutions.
For OEM Equipment Manufacturers: We provide comprehensive OEM/ODM customization, including custom housing, labeling, branding (private labeling), and tailored technical specifications to seamlessly integrate with your machinery.
For Industrial Distributors & Traders: We offer flexible customization in packaging, product ranges, and technical parameters, helping you differentiate your portfolio and win more local bids.
Why Partner with Us for Custom Sourcing?
One-Stop Engineering Alignment: You don’t have to deal with multiple factories. We translate your technical requirements into precise manufacturer blueprints.
Strict Quality & Compliance Safeguard: We oversee the entire customization and production process in China, ensuring the final customized product meets your local standards and certifications.
Our Ultimate Value: We don’t just sell what’s on the shelf. We find, customize, and deliver the most suitable and cost-effective product for your unique application.
Why is a 750KVA three phase pad mounted transformer preferred for dense urban load centers?
A 750KVA pad-mounted transformer is preferred because its compact, “combined transformer” structure integrates the core, windings, and high/low-voltage cabinets into a single low-profile enclosure. This small volume allows it to be installed directly on ground-level concrete pads near the center of electrical load. Placing the transformer closer to consumer infrastructure minimizes transmission power sags, reduces low-voltage cable costs, and eliminates the need for expensive overhead installations.
What is the operational difference between loop feed and radial feed configurations in a pad-mounted transformer?
The primary operational difference lies in system redundancy and network routing flexibility. A loop feed configuration provides two distinct source paths, enabling the 750KVA transformer to connect within a ring network so power can flow from either direction during upstream cable failures or maintenance shutdowns. A radial feed configuration features a single point-of-use source line, functioning as a dedicated terminal step-down unit for an individual factory, railway section, or solar array.
How does a fully sealed and insulated structure guarantee public and operator safety?
It guarantees absolute safety by utilizing a completely enclosed, tamper-proof dead-front cabinet layout that leaves zero high-voltage or low-voltage components exposed to the environment. All live connections are safely housed within locked, robust steel compartments. This fully insulated structure prevents accidental contact by field technicians or the public, eliminates the risk of environmental flashovers from dust and moisture, and ensures safe, maintenance-free operation in outdoor spaces.
Can this 750KVA step down distribution transformer handle the variable loads of solar and wind installations?
Yes, this 750KVA transformer is specifically engineered with low temperature-rise characteristics and a robust continuous overload capability to handle renewable energy profiles. Solar and wind networks frequently experience rapid generation fluctuations and thermal spikes. By combining high-purity copper windings with optimized fluid convection paths, the transformer safely absorbs cyclic overcurrent surges without accelerating insulation degradation or risking thermal runaway.
How do the low loss and low noise metrics of this pad mounted unit improve grid upgrade efficiency?
They improve efficiency by reducing continuous energy dissipation and meeting strict municipal environmental codes. The transformer utilizes premium high-permeability steel cores and precision winding layouts to minimize both idling no-load losses and full-load copper losses. This high-efficiency design retains unbilled power within the distribution network, while its dampened low-noise operation ensures the unit can run quietly in residential areas, corporate parks, and urban centers.
How does the integrated ±2 × 2.5% H.V. tap range handle incoming voltage fluctuations across long overhead or buried lines?
The ±2 × 2.5% high-voltage tap changer allows service engineers to manually adjust the internal transformer turn ratio to compensate for line voltage drops or surges. When connected to a long buried cable run that suffers a voltage drop, adjusting the de-energized tap changer recalibrates the primary input threshold. This precise mechanical correction stabilizes the secondary step-down output, maintaining a steady current delivery to terminal commercial hardware.
